Copper Tube End Reducing Forming and Spinning Machine For Filter Making Send to Turkey
2024-08-30
Products Description
1.The spinning machine can automatically cut and trim the nozzle, the cutting is neat, high degree of automation, With high work efficiency, the convenient programming and stable, and the performance is reliable.
2.The electric control system adopts Zhongda Dentsu PUTNC-H4-2 numerical control system + two sets of Delta servo system.
Features
1.The spinning machine can automatically cut and trim the nozzle, the cutting is neat, high degree of automation, With high work efficiency, the convenient programming and stable, and the performance is reliable.
2.The electric control system adopts Zhongda Dentsu PUTNC-H4-2 numerical control system + two sets of Delta servo system.
Specification
| Item | Data |
| Tube diameter range | Φ16mm-Φ32mm |
| Working thickness | 0.6-2mm |
| Tube length | 60≤L≤200mm |
| Power | 380V（AC）±10%，50HZ |
| Air pressure | 0.5±0.1MPa |
| Control system | CNC system |
| X axis | 200mm |
| X axis precision | ±0.05 |
| X Axis speed | 300mm/S |
| Y axis stroke | 100mm |
| Y axis precision | ±0.05 |
| Y axis speed | 150mm/S |
| Material Moving | Automatic /Manual option |
| Working stations | 1 station |
| Working way | Cold spinning |
| Operation | Auto/manual/Jog |
| Clamp way | Hydraulic air core rotary cylinder |
| Hydraulic press power | 5MPa |
| Capacity | 30s/pc |
| Motor power | 7Kw |
| Hydraulic power | 3KW (Total 6Kw) |
| Dimension | 1800*900*1500（mm） |
| Weight | 1ton |
