Spiral Round Heater Pipe Machine M-16
Dual servo motors drives for axial and radial travel, precision controls.
PLC controls and HMI, friendly operation.
Hydraulic bending, high performance.
Overload protection and human care.
The machine tool is mainly composed of mechanical system, hydraulic system and electrical control system. The structure is reasonable and the performance is stable. It can be used for cold forming of metal profiles, with high precision, stable molding, simple operation and high production efficiency!
Parameter
Item | Data | |
|---|---|---|
| Max bending capacity(mm) | ï¿ 16*2 | |
| Min roll bending diameter(mm) | ≧Diameter 6D | |
| Rolling speed(mm/ sec) | 400 | |
| Motor power(KW) | 2.2 | |
| Oil pump(L) | 14 | |
| Max pressure(Mpa) | 16 | |
Item | Data | |
|---|---|---|
| Oil(L) | 120 | |
| Mould central height(mm) | 35 | |
| Total power(KW) | 4.5 | |
| Voltage(V) | Customized | |
| Dimension(mm) | 1500*650*1200 | |
Features
This robust 3-system integrated machine (mechanical/hydraulic/electrical) achieves high-speed, high-accuracy rounding of metal profiles (tubes, bars, strips) up to Ø16×2mm, delivering ±0.02mm tolerance at 400mm/sec rolling speeds (6D min. bend radius). Engineered for 24/7 sheet metal and tubular fabrication with a 4.5kW energy-efficient drive.
Dynamic Hydraulic Force Control
16MPa max pressure + 14L pump + 120L oil reservoir ensures smooth, consistent rolling under 350kg loads. Auto-pressure compensation prevents deformation of thin-walled profiles (≥0.4mm).
Zero-Slip Precision Feed System
Dual hardened rollers (35mm center height) + servo-guided alignment achieves <0.5% ovality at 6D diameters. 650mm-wide bed allows processing of 1,500mm-long stock in single passes.
Adaptive Speed-to-Tolerance Optimization
400mm/sec rolling with 2.2kW torque motor + interlock sensors. Maintains ±0.03mm circularity even at 1mm thickness – ideal for stainless tubes, copper conduits, and structural aluminum.
Plug-and-Play Workshop Integration
Compact footprint (1.5×0.65×1.2m) compatible with 380V/220V customizable voltage. Pre-lubricated gearboxes enable <10-minute setup – no foundation bolts required.
